ENConneCtion Diagrams anD aCCessories

660Y1400 - A

Setting the MCBA

Initial

Adjusted

DESCRIPTION

1. 60 1. 60

Maximum temperature of preset Domestic Hot Water temperature

2. 0 1 2. 0 1

00 : DHW mode “OFF”

01 : DHW mode “ON”

3. 0 1 3. 0 1

00 : Heating mode “OFF”

01 : Heating mode “ON”

4. 85 4. 85

Maximum temperature of the heating circuit (must be higher than the DHW temperature.

CASCADE INSTALLATION

For information on the installation of several HeatMaster® TC boilers in a cascade, please contact your ACV representative.
