MCBA PArAMeters for the sPeCiAlist
660Y1400 - A
Factory settings Factory settings
STEP Display Parameter Description HM 25 TC HM 35 TC HM 45 TC HM 70 TC HM 85 TC HM 120 TC HM 71 HM 101 HM 201
p. 4 1
Domestic hot water block time sec. X 10,2.
. 00 . 00 . 00 . 00 . 00 . 00 . 00 . 00 . 00
p. 4 2
DHW CH locking time [sec. x 10,2].
. 00 . 00 . 00 . 00 . 00 . 00 . 00 . 00 . 00
p. 4 3
Max. operating time in DHW mode min.
. 00 . 00 . 00 . 00 . 00 . 00 . 00 . 00 . 00
p. 4 5
00 : High temperature circuit - heating pump controlled by room thermos-
tat - DHW priority active.
50 : Controlled circuit [outdoor sensor and AM3-11 module] - circulator
controlled by the room thermostat - DHW priority inactive.
. 00 . 00 . 00 . 00 . 00 . 00 . 00 . 00 . 00
p. 4 6
DHW PRODUCTION TYPE:
This parameter may be modified in any way on a HeatMaster®
. 02 . 02 . 02 . 02 . 02 . 02 . 1 2 . 1 2 . 1 2
p. 4 7
Manual fan speed (test)
.-0 1 .-0 1 .-0 1 .-0 1 .-0 1 .-0 1 .-0 1 .-0 1 .-0 1
p. 5 3
1
st
: special pump [0 = disabled]
2
nd
position: minimum disable cycle [0 = disabled]
. 00 . 00 . 00 . 00 . 00 . 00 . 00 . 00 . 00
p. 57
Pre-spark [sec.
. 00 . 00 . 00 . 00 . 00 . 00 . 00 . 00 . 00
p. 6 4
Extra pre-sweep [sec.
. 25 . 25 . 25 . 25 . 25 . 25 . 25 . 25 . 25
p. 65
Post ventilation [sec.
. 30 . 30 . 30 . 30 . 30 . 30 . 30 . 30 . 30
p. 6 6
Fan speed during post-ventilation tr=min. X 100
. 25 . 25 . 25 . 25 . 25 . 25 . 30 . 30 . 30
p. 7 6
Opening time of the
2
nd
CH circuit valve[sec. X 15
. 1 0 . 1 0 . 1 0 . 1 0 . 1 0 . 1 0 . 1 6 . 1 6 . 1 6
p. 77
Factor "I" of the 2
nd
CH circuit
. 1 0 . 1 0 . 1 0 . 1 0 . 1 0 . 1 0 . 1 0 . 1 0 . 1 0
p. 7 8
Fan factor "I" (raise)
. 20 . 20 . 20 . 40 . 40 . 1 0 . 60 . 60 . 1 0
p. 7 9
Fan factor "I" (lower)
. 1 0 . 1 0 . 1 0 . 20 . 20 . 05 . 1 0 . 1 0 . 50
p. 8 3
Max. T5 temperature limit . C°.
. 120 . 120 . 120 .1 20 .1 20 .1 20 .1 20 .1 20 .1 20
