22 American Dryer Corp. 113066 - 17
CAUTION: The dryer must be grounded. A ground lug has been provided for this purpose.
IMPORTANT: A SEPARATE CIRCUIT SERVICING EACH DRYER MUST BE
PROVIDED.
The only electrical connections to the dryer are the 3-phase (3ø) leads (L1, L2, L3, and sometimes
Neutral) and ground. Single-phase (1ø) power for the control circuit is done by the factory at the
contactor (relay), and no other wiring connections are.
