113066 -17 www.adclaundry.com 23
GAS / STEAM
ELECTRICAL SERVICE SPECIFICATIONS (PER POCKET)
IMPORTANT:
NOTES
: A.
B.
C.
208 VAC AND 230/240 VAC ARE NOT THE SAME. When ordering,
specify exact voltage.
When fuses are used they must be dual element, time delay, current
limiting, class RK1 or RK5 ONLY. Calculate/determine correct fuse
value, by applying either local and/or National Electrical Codes to
listed appliance amp draw data.
Circuit breakers are thermal-magnetic (industrial) motor curve type
ONLY. For others, calculate/verify correct breaker size according to
appliance amp draw rating and type of breaker used.
Circuit breakers for 3-phase (3ø) dryers must be 3-pole type.
SERVICE
VOLTAGE
PHASE
WIRE
SERVICE
APPROX.
AMP DRAW
CIRCUIT
BREAKER
60 Hz 50 Hz
NON-REVERSING
120 1ø 2 12
—
15
208 1ø 2 7.1
—
15
220 1ø 2 7 5.3 15
230 1ø 2
—
4.9 15
240 1ø 2 6.5 4.2 15
208 3ø 3 3
—
15
220 3ø 3 3.8 3.7 15
230 3ø 3
—
3.6 15
240 3ø 3 3.2 3.6 15
380 3ø 3 2
—
15
380-400 3ø 3
—
2.2 15
416 3ø 3
—
2.3 15
440 3ø 3 2.1 2.1 15
460 / 480 3ø 3 2.1
—
15
REVERSING
208 3ø 3 5
—
15
220 3ø 3 5.9 6.5 15
230 3ø 3
—
6.4 15
240 3ø 3 5.5 6.8 15
380 3ø 3 2.9
—
15
380-400 3ø 3
—
3.4 15
416 3ø 3
—
3.6 15
440 3ø 3 3.1 3.3 15
460 / 480 3ø 3 3.2
—
15
Check your national and local codes for breaker and wire sizes 10/5/16
IMPORTANT: The dryer must be connected to the electric supply shown on the data label that is
affixed to either the back side of the upper control door or left side panel/wall area
behind the control door. In the case of 208 VAC or 240 VAC, the supply voltage
must match the electric service specifications of the data label exactly.
IMPORTANT: The wire size must be properly sized to handle the related current.
WARNING: 208 VAC AND 240 VAC ARE NOT THE SAME. Any damage done to dryer
components due to improper voltage connections will automatically VOID THE
WARRANTY.
NOTE: ADC reserves the right to make changes in specifications at any time without notice or
obligation.
