ADC AD-50 - Page 28

24 American Dryer Corp. 113066 - 17
Check your national and local codes for breaker and wire sizes 2/16/22
Check your national and local codes for breaker and wire sizes 3/23/17
ELECTRIC
ELECTRICAL SERVICE SPECIFICATIONS (PER POCKET)
IMPORTANT:
NOTES
: A.
B.
C.
208 VAC AND 230/240 VAC ARE NOT THE SAME. When ordering,
specify exact voltage.
When fuses are used they must be dual element, time delay, current
limiting, class RK1 or RK5 ONLY. Calculate/determine correct fuse
value, by applying either local and/or National Electrical Codes to
listed appliance amp draw data.
Circuit breakers are thermal-magnetic (industrial) type ONLY. For
others, calculate/verify correct breaker size according to appliance
amp draw rating and type of breaker used.
Circuit breakers for 3-phase (3ø) dryers must be 3-pole type.
SERVICE
VOLTAGE
PHASE
WIRE
SERVICE
OVEN
kW
APPROX.
AMP DRAW
CIRCUIT
BREAKER
60 Hz 50 Hz
REVERSING – Three-Phase Heat, Three-Phase Motor
208 3ø 3 24 72
—
90
208 3ø 3 30 88
—
125
220 3ø 3 20 58 59 80
220 3ø 3 26 74 75 100
230 3ø 3 22 61 62 80
230 3ø 3 28 76 77 100
240 3ø 3 24 63 65 80
240 3ø 3 30 77 79 100
380 3ø 3 20 33 34 50
380 3ø 3 26 43 43 60
400 3ø 3 22
—
35 50
400 3ø 3 28
—
44 60
416 3ø 3 24
—
37 50
416 3ø 3 30
—
45 60
440 3ø 3 20 29
—
50
440 3ø 3 26 37
—
50
460 3ø 3 22 31
—
50
460 3ø 3 28 38
—
50
480 3ø 3 24 32
—
50
480 3ø 3 30 39
—
50
575 3ø 3 30 34
—
50
ELECTRIC
ELECTRICAL SERVICE SPECIFICATIONS (PER POCKET)
IMPORTANT:
NOTES
: A.
B.
C.
208 VAC AND 230/240 VAC ARE NOT THE SAME. When ordering,
specify exact voltage.
When fuses are used they must be dual element, time delay, current
limiting, class RK1 or RK5 ONLY. Calculate/determine correct fuse
value, by applying either local and/or National Electrical Codes to
listed appliance amp draw data.
Circuit breakers are thermal-magnetic (industrial) type ONLY. For
others, calculate/verify correct breaker size according to appliance
amp draw rating and type of breaker used.
Circuit breakers for 3-phase (3ø) dryers must be 3-pole type.
SERVICE
VOLTAGE
PHASE
WIRE
SERVICE
OVEN
kW
APPROX.
AMP DRAW
CIRCUIT
BREAKER
60 Hz 50 Hz
NON-REVERSING – Single-Phase Heat, Single-Phase Motor
208 1ø 2 20 103
—
150
208 1ø 2 30 151
—
200
220 1ø 2 17 84
—
125
220 1ø 2 17
—
83 100
220 1ø 2 20 97
—
125
230 1ø 2 18.5 87
—
125
230 1ø 2 18.5
—
85 100
230 1ø 2 22 102
—
150
240 1ø 2 20 90 88 125
240 1ø 2 24 107
—
150
NON-REVERSING – Three-Phase Heat, Single-Phase Motor
208 3ø 3 24 74 — 100
208 3ø 3 30 90 — 125
220 3ø 3 20 59 — 80
220 3ø 3 26 75 74 100
220 3ø 3 30 86 — 125
230 3ø 3 22 62 60 80
230 3ø 3 28 73 75 100
240 3ø 3 24 64 — 80
240 3ø 3 30 79 72 100
380 3ø 3 20 37 — 50
380 3ø 4 20 — 36 50
380 3ø 4 26 46 45 60
400 3ø 4 22 — 37 50
400 3ø 4 28 — 45 60
416 3ø 4 24 — 38 50
416 3ø 4 30 48 46 60
NON-REVERSING – Three-Phase Heat, Three-Phase Motor
208 3ø 3 24 70 — 90
208 3ø 3 30 86 — 125
220 3ø 3 20 56 56 80
220 3ø 3 26 72 — 100
220 3ø 3 26 — 72 90
230 3ø 3 22 58 59 80
230 3ø 3 28 73 74 100
240 3ø 3 24 61 61 80
240 3ø 3 30 75 76 100
380 3ø 3 20 32 33 50
380 3ø 3 26 42 42 60
400 3ø 3 22 — 34 50
400 3ø 3 28 — 43 60
416 3ø 3 24 — 36 50
416 3ø 3 30 — 44 60
440 3ø 3 20 28 — 40
440 3ø 3 26 36 — 50
460 3ø 3 22 30 — 40
460 3ø 3 28 37 — 50
480 3ø 3 24 31 — 40
480 3ø 3 30 38 — 50
