Tamper input (where fitted)
Fault reporting to Monitoring Center
Transmission interface/path fault
Relay outputs
Maximum operating voltage
24V DC
Maximum current rating
100mA DC
Power supply
Supply voltage
IRIS-4 160 9V to 15V DC
others 9V to 28V DC
Typical current
IRIS-4 160 At 12V DC: 83mA
IRIS-4 200/220/240 At 12V DC: 138mA / 110mA / 153mA
At 24V DC: 78mA / 63mA / 86mA
IRIS-4 400/420/440
At 12V DC: 157mA / 120mA / 160mA
At 24V DC: 87mA / 68mA / 89mA
IRIS-4 440G
At 12V DC: 137mA
At 24V DC: 73mA
IRIS-4 620/640
At 12V DC: 68mA / 89mA
At 24V DC: 55mA / 76mA
IRIS-4 620D/640D At 12V DC: 134mA /142mA
At 24V DC: 58mA / 81mA
Maximum current At 12V DC and 24V DC: 1A
Recommended external PSU 12V DC 1A 12 Watt
Note: The Radio Equipment Directive states that the length of the
power cable may only be a maximum of 3 meters long.
Environmental
Operating temperature range
-10°C to 55°C
Operating humidity range 95% max., non-condensing
Weights and dimensions: The 160
Physical dimensions 11 cm x 17.5 cm x 4.5 cm
PCB weight 400 grams
Fully packaged weight 600 grams
Weights and dimensions: The 2xx
Physical dimensions 19 cm x 13 cm x 4 cm
PCB weight 550 grams
Fully packaged weight 750 grams
Weights and dimensions: The 4xx
Physical dimensions 14 cm x 11.5 cm x 1.5cm
PCB weight 300 grams
Fully packaged weight 500 grams
Weights and dimensions: The 6xx
Physical dimensions 12 cm x 9 cm x 2cm
PCB weight 60 grams
Fully packaged weight 160 grams
