11 Technical specifications
Wi-Fi (if applicable)
Standard IEEE 802.11 b/g
Connection 2.4GHz b/g/n with internal PCB chip antenna
Fault detection Loss of association/data
Ethernet (if applicable)
Standard UTP 10/100 Base T with auto-negotiation
Connection RJ45 socket for CAT5 cabling
IP addressing Dynamic (DHCP) or fixed
Fault detection
Loss of Ethernet synchronization
Cellular (if applicable)
IRIS-4 models (from REV A25)
LTE (4G) Cat1 B28A(700MHz), B20(800MHz), B8(900MHz)
UMTS (3G) B8(900MHz), B3(1800MHz), B1(2100 MHz)
GPRS (2G) B8(900MHz), B3(1800MHz)
IRIS-4 240AP
LTE (4G) Cat1 B28(700MHz), B5/B26/B18/B19(800MHz)
B8(900MHz), B3/B9(1800MHz), B1(2100MHz)
UMTS (3G) B5/B6/B19(800MHz), B8(900MHz), B1(2100MHz)
IRIS-4 models (up to REV A24)
LTE (4G) Cat4 B20(800MHz), B8(900MHz), B3(1800 MHz)
B1(2100MHz), B7(2600MHz)
UMTS (3G) B8(900MHz), B1(2100 MHz)
GPRS (2G) B8(900MHz), B3(1800MHz)
Connection SMA socket for antenna
Fault detection
Loss of registration with network
IP
TCP ports (outbound)
53165 (Alarms and Polling)
51292 (Diagnostic and Reflashing)
10001 (Upload/Download)
Alarm transmission
Interface to Monitoring Center
ISA or IRIS Management Suite
via EN 50136-2 pass-through mode
Dial capture interface to alarm panel Two-wire interface via terminal block
Serial interface to alarm panel RS485, TTL, RS232, RS232
PIN Inputs interface to alarm panel
Maximum input voltage range 0V to +24V
Note: Cabling must
not exceed 3 meters
Input ‘low’ (alarm) threshold < 1V
Input ‘high’ (restore) threshold > 2V
Internal pull-up impedance 10K to 3.3V supply
Alarm protocols
SIA (level 1 to 3) reference SIA DC-03-1990.01(R2003.10)
Contact ID reference SIA DC-05-1999.09
FF (Scancom)
Robofon (Dial capture only)
Telim (Dial capture only)
CESA (Dial capture only)
Tamper detection reporting to
Monitoring Center
Dial capture interface
Serial Interfaces
Pin inputs
Lid & back tamper (cased units)
