In the following installation process, it is required to connect the servos to the AdeeptPixie The
AdeeptPixie will automatically check the servo angle and rotate it to the appropriate position.
Connect the servo to D2-D13 of the interfaces in
the red box at the angle shown in the figure.
When debugging the servo,
switch to "on" and switch to "off"
after the debug is completed.
