Assemble the following components
Effect diagram after assembling
3.Assembly
3.1.Preparations before Assembly
1.Connect the Adeept Ultrasonic Module with 4-Pin wire.
Connect the WS2812 LED Module
Please note that the end marked with white strip is the signal input, and the end without
white strip is the signal output.
Adeept Ultrasonic Module x1
The end marked with white strip is the
signal input
The connection between two
WS2812 LED
