49
The assembled robot connect
the servo and IR receiver
from here after finishing
assembling the robot.
D12
D13
D11
D5
D6
D7
D3
D4
D8
D9
D2
Connect the servo to the
corresponding interface
according to the numbers
below.
D10
D14
