3.Assembly
3.1. Preparations before Assembly
1.Connect the Raspberry Pi Camera and the ribbon.
Assemble the following components
Raspberry Pi Camera x1
Raspberry Pi Camera Ribbon x1
Effect diagram after assembling
Note: That in the next operation, the Pi Camera of the Raspberry Pi should always
be connected to the Raspberry Pi, and do not reverse the wires of the Raspberry Pi.
