Adexa HZB-45 - SPECIFICATIONS; DIMENSIONS;CONNECTIONS; Rating

5
SPECIFICATIONS
1) DIMENSIONS/CONNECTIONS
2) Rating
POWER SUPPLY VOLTAGE
1Phase, 220-240/50Hz
MODEL HZB-45
CLIMATE CLASS SN/N/ST/T
ELECTRICAL PROTECTION CLASS I
ICE MAKING RATING (Amps) 1.7 Amp
ICE HARVEST RATING (Amps) 2.2 Amp
ICE MAKING CAPACITY (KG/24H) 45kg/24Hour
*
REFRIGERANT CHARGE R290, 95g
VESICANT
C
5
H
10
NET WEIGHT/GROSS WEIGHT(KG)
26kg
UNIT DIMENSIONS(W X D X H) (mm)
448 x 400 x 798
CONNECTION POWER CORD---- 0.75 mm
2
WATER SUPPLY----6.35mm diamete
DRAIN----Φ16
SYLPHON BELLOWSS(REAR)
WATER CONSUMPTION(L/24H) 50L
MAX ICE STORAGE CAPACITY(KG) 15kg
ACCESSORIES SHOVEL, INSTALLATION KITS
RUNNING CONDITIONS ROOM TEMP 10-38℃
WATER SUPPLY TEMP 5-35℃
WATER SUPPLY PRESSURE 0.04-0.6 MPa
NOTE *: TESTED AT 21℃ RO OM TEMPERATURE AND 10℃ WATER TEMPERATURE.
Water
Drainage Port
Water Inlet
Port
