INSTALLATION
CLAMP INSTALLATION
This fixture features an attachment point for a mounting clamp located at the top the mounting
bracket (see the illustration below). When mounting the fixture to a truss or any other suspended or
overhead installation, be sure to secure an appropriately rated clamp (not included) to the mounting
bracket. Additionally, it is also necessary to attach a separate SAFETY CABLE of the appropriate
weight rating to the fixture, with one end of the safety cable secured around the mounting bracket
and the other end secured to a suitable mounting point on the truss or mounting surface.
SAFETY CABLE:
ALWAYS ATTACH A SAFETY CABLE WHENEVER INSTALLING THIS FIXTURE
IN A SUSPENDED ENVIRONMENT TO ENSURE THAT THE FIXTURE WILL NOT
FALL IF THE CLAMP FAILS.
MOUNTING CLAMP
ATTACHMENT POINT
SAFETY CABLE
LOOPED AROUND
BRACKET
