REAR LAYOUT & FUNCTIONS
1. IR receiver: To receive the IR signal;
2. MIC: Used to receive music for sound active;
3. Button:
MENU
To select the programming function s
▼ DOWN
To go backward in the selected functions
▲ UP
To go forward in the selected functions
ENTER
To confirm the selected functions
4. Function Display: Used to show the various menus and the selected functions;
5. DMX IN/OUT: For DMX512 links, use 3-pin XLR plug cable to translate the DMX signa l;
6. POWER IN: Used to connect to power supply.
