ADJ Products, LLC - www.adj.com - Element QA User Manual Page 27
Element QA Trouble Shooting
Element QA Cleaning
Listed below are a few common problems the user may encounter, with solutions.
Unit not responding to DMX:
1. Check that the DMX cables are connected properly and are wired correctly (pin 3 is “hot”; on
some other DMX devices pin 2 may be ‘hot’). Also, check that all cables are connected to the right
connectors; it does matter which way the inputs and outputs are connected.
Unit does not respond to sound:
1. Quiet or high pitched sounds will not activate the unit.
2. Make sure that Sound Active mode is activated.
Due to fog residue, smoke, and dust cleaning the internal and external optical lenses must be car-
ried out periodically to optimize light output.
1. Use normal glass cleaner and a soft cloth to wipe down the outside casing.
2. Clean the external optics with glass cleaner and a soft cloth every 20 days.
3. Always be sure to dry all parts completely before plugging the unit back in.
Cleaning frequency depends on the environment in which the fixture operates (i.e. smoke, fog resi-
due, dust, dew).
Element QA Fuse Replacement
Disconnect the unit from its power source. Remove the power cord from the unit. Once the cord has
been removed, you will find that the fuse holder is located inside the power socket. Insert a flat-head
screw driver into the power socket and gently pry out the fuse holder. Remove the bad fuse and
replace with a new one. The fuse holder also has a holder for a spare fuse.
Element QA Multiple Unit Power Linking
Element QA Optional Accessories
ORDER CODE ITEM
EPC600 6-PACK SKB CASE
EFC800 8-PACK CHARGING CASE
With this feature you can connect the xtures to one another using the power cable input and
output sockets.
NOTE: USE CAUTION WHEN POWER LINKING OTHER FIXTURES AS THE POWER
CONSUMPTION OF OTHER MODEL FIXTURES MAY EXCEED THE MAX POWER OUTPUT ON
THIS FIXTURE! CHECK SILK SCREEN FOR MAX AMPS.
