ADJ Products, LLC - www.adj.com - Element QA User Manual Page 23
Element QA WiFly Primary-Secondary Set Up
WiFly Primary-Secondary Set Up:
This function will allow you to link units together via WiFly to run in a Primary-Secondary setup.
1. Follow the instructions on page 22 to set the WiFly address and to activate WiFly. The addresses
on each fixture must be the same.
2. After you have set the WiFly address, select your “Primary” unit and set your desired operating
mode.
3. Set the “Primary” unit to your desired mode of operation. On the “Secondary” unit(s) press the
MODE
button until “SEcd” is displayed. See page 22 “Secondary Setting”.
4. If everything is set up correctly, the “Secondary” units will start following the “Primary” unit.
Element QA WiFly Set Up
This unit can only be controlled using WiFly. Your DMX controller must be connected to a ADJ WiFly
Transceiver to use this function. You are able to communicate up to 2500 feet/760 meters (open line
of sight).
1. Follow the instructions on page 22 to set the WiFly address and to activate WiFly. The address
must match the address set on the WiFly WiFly Transceiver.
2. After you have set the WiFly address, follow the DMX instructions on page 21 to select your
desired DMX Channel mode and set your DMX address.
3. Apply power to the ADJ WiFly Transceiver. The fixture must be set up first before you apply
power to WiFly Transceiver.
4. If everything is set up properly and the fixture is receiving a Wireless signal, you should now be
able to control it with a DMX controller.
Element QA Primary-Secondary Set Up
Primary-Secondary Set Up:
This function will allow you to link units together to run in a Primary set-up. In a Primary-
Secondary set up one unit will act as the controlling unit and the others will react to the controlling
units built-in programs. Any unit can act as a Primary or as a Secondary however, only one unit can
be programmed to act as the "Primary".
Primary-Secondary Connections and Settings:
1. Daisy chain your units via the XLR connector on the rear of the unit. Use standard XLR data
cables to link your units together. Remember that the Male XLR connector is the input and the
Female XLR connector is the output. The first unit in the chain (primary) will use the female XLR
connector only. The last unit in the chain will use the male XLR connector only.
2. Connect the first “Secondary” unit to the “Primary.”
3. Set the “Primary” unit to your desired mode of operation. On the “Secondary” unit(s) press the
MODE
button until “Secd” is displayed. See page 22 “Secondary Setting".
