ADJ Products, LLC - www.adj.com - Flat Par QA5XS User Manual Page 15
Flat Par QA5XS 2 Channel Mode
Channel Value Function
1 0 - 255 COLOR MACROS
(See 1 Channel DMX mode for colors)
2 0 - 255 DIMMER 0% - 100%
Flat Par QA5XS 3 Channel Mode
Channel Value Function
1 0 - 255 COLOR MACROS
(See 1 Channel DMX mode for colors)
2 0 - 255 DIMMER 0% - 100%
3 STROBING
0 - 15 OFF
16 - 255 STROBING SLOW - FAST
Flat Par QA5XS 1 Channel Mode
Channel Value Function
1 COLOR MACROS
0 - 15 OFF
16 - 31 RED
32 - 47 GREEN
48 - 63 BLUE
64 - 79 AMBER
80 - 95 RED & GREEN
96 - 111 RED & BLUE
112 - 127 RED & AMBER
128 - 143 GREEN & BLUE
144 - 159 GREEN & AMBER
160 - 175 BLUE & AMBER
176 - 191 RED & GREEN & BLUE
192 - 207 RED & GREEN & AMBER
208 - 223 RED & BLUE & AMBER
224 - 239 GREEN & BLUE & AMBER
240 - 255 RED & GREEN & BLUE & AMBER
ADJ Products, LLC - www.adj.com - Flat Par QA5XS User Manual Page 14
3. Now you may connect the fixture via the XLR connections to any
standard DMX controller. Please see pages 15-20 to for a detailed
descriptions of the DMX modes, values, and traits.
• If the Red LED’s glow you are in DMX Mode 1: 1 Channel Mode.
• If the Green LED’s glow you are in DMX Mode 2: 2 Channel
Mode.
• If the Blue LED’s glow you are in DMX Mode 3: 3 Channel
Mode.
• If the Amber LED’s glow you are in DMX Mode 4: 4 Channel
Mode.
• If the Red & Green LED’s glow you are in DMX Mode 5: 5
Channel Mode.
• If the Red & Blue LED’s glow you are in DMX Mode 6: 6 Channel
Mode.
• If the Red & Amber LED’s glow you are in DMX Mode 7: 7
Channel Mode.
• If the Green & Blue LED’s glow you are in DMX Mode 8: 8
Channel Mode.
Flat Par QA5XS ADJ LED RC Operation
