ADJ Products, LLC - www.adj.com - Mega Bar RGBA User Manual Page 24
Mega Bar RGBA Specifications
Model:
Mega Bar RGBA
Voltage: 100V ~ 240V/50~60Hz
LEDs: 320 x 10mm LED’s (64 Red, 96
Green, 96 Blue, & 64 Amber)
Beam Angle: 30 Degrees
Working Position: Any safe working position
Power Draw: 32W
Power Cord Daisy Chain:20 Fixtures Max.
Fuse: 1 Amp
Weight: 6lbs./ 2.7Kgs.
Dimensions: 41.75” (L) x 3” (W) x 5.75” (H)
1060 x 73 x 145mm
Colors: RGBA Color Mixing
DMX Channels: 7 DMX Modes: 4 Channel Mode,
6 Channel Mode, 7 Channel Mode,
9 Channel Mode, 10 Channel
Mode, 18 Channel Mode, & 34
Channel Mode
Warranty: 3 Year (1,095 days) Limited
Warranty
Auto Sensing Voltage: This xture contains a automatic voltage
switch, which will auto sense the voltage when it is plugged into the power
source.
Please Note: Specications and improvements in the design of this unit
and this manual are subject to change without any prior written notice.
