ADJ STINGER - System Menu; LCD Display Lock; ADDR - DMX Address Setting; SHOW - Show mode

ADJ Products, LLC - www.adj.com - Stinger Instruction Manual Page 12 ADJ Products, LLC - www.adj.com - Stinger Instruction Manual Page 13
LCD DISPLAY LOCK:
The display will lock after 30 seconds. Press and hold the MENU
button for at least 10 seconds to unlock the display and access the
menu.
ADDR - DMX Address Setting.
1. Press the either the MENU button until “ADDR” is displayed, press
ENTER.
2. The current DMX address will now be displayed. Press the UP or
DOWN buttons to nd your desired address. Press ENTER to set
your desired DMX address.
SHOW - Show mode. There are 7 show modes to
choose from.
1. Press the MENU button until “Show” is displayed, press ENTER.
2. The display will show one of seven auto show modes. Use the UP
or DOWN buttons to nd your desired show and press ENTER to
activate. See the system menu on page 11 for the dierent shows.
SOUN - Sound Active mode with adjustable sound sen-
sitivity.
1. Press the MENU button until “Soun” is displayed, press ENTER.
2. Use the UP or DOWN buttons to either turn sound activity “On” or
“O”, and press ENTER.
3. Press the MENU button until “Sens” is displayed, and press
ENTER. Use the UP or DOWN buttons to adjust the sound sensitivity.
VER - Use this function to display the Software version of
the unit.
1. Press the either the MENU button until “VER” is displayed, press
ENTER.
2. The display will show the software version.
Stinger System Menu
Universal DMX Control: This function allows you to use a univer-
sal DMX-512 controller to control the patterns, rotation and strobing.
A DMX controller allows you to create unique programs tailored to
your individual needs.
1. The Stinger is a 10 DMX channel DMX fixture. See pages 15-16
for detailed description of the DMX values and traits.
2. To control your fixture in DMX mode, follow the set-up procedures
on pages 7-9 as well as the set-up specifications that are
included with your DMX controller.
3. Follow the instructions on page 12 to set the DMX address.
4. For longer cable runs (more than a 100 feet) use a terminator on
the last fixture.
5. For help operating in DMX mode consult the manual included
with your DMX controller.
Sound Active Mode: This mode allows a single unit or several units
linked together, to run to the beat of the music.
1. Press the MENU button until “Soun” is displayed, and press
ENTER.
2. Press the UP or DOWN buttons to either activate sound active
mode or deactivate, and press ENTER. The unit will now run to
the beat of the music.
3. The sound sensitivity can be adjusted by pressing the MENU
button until “Sens” is displayed, and then press ENTER. Use the
UP or DOWN buttons to adjust the sound sensitivity, 0 being the
least sensitive, and 99 being the most sensitive.
Show Mode: This mode allows a single unit or several units linked
together, to run to a built-in program.
1. Press the MENU button until “Show” is displayed, and press
ENTER.
2. Press the UP or DOWN buttons to nd your desired show and
press ENTER. The unit will now run your chosen built-in program.
Stinger Operation
