ADJ STINGER - Master-Slave Set Up; Master-Slave Set Up Procedure; DMX Traits; Channel 1-3 DMX Traits

ADJ Products, LLC - www.adj.com - Stinger Instruction Manual Page 14 ADJ Products, LLC - www.adj.com - Stinger Instruction Manual Page 15
Stinger DMX Traits
Channel Value Function
1 AUTO RUN/SOUND ACTIVE
0 - 9 BLACKOUT
10 - 39 SIX COLORS LED AUTO RUN
40 - 69 WHITE LEDS AUTO RUN
70 - 99 LASER AUTO RUN
100 - 129 AUTO RUN MIXING
130 - 159 SIX COLORS & STROBING
160 - 189 LASER & STROBING
190 - 219 LEDS, LASER, & STROBING
220 - 255 DMX MODE
2 RGBWAP
0 - 9 BLACKOUT
10 - 198 COLOR MACROS
199 - 225 COLOR CHASE 1
226 - 255 COLOR CHASE 2
3 AUTO RUN
0 - 255 AUTO RUN SPEED SLOW - FAST
4 LED STROBE
0 - 9 NO STROBE
10 - 244 LED STROBE SLOW - FAST
245 - 255 SOUND ACTIVE STROBING
5 WHITE LEDS
0 - 9 BLACKOUT
10 - 135 WHITE OUTPUT POSITION
136 - 255 WHITE OUTPUT CHASE
6 WHITE LED STROBE
0 - 127 CHASE SLOW - FAST (NO STROBE)
128 - 255 CHASE SLOW - FAST (STROBING)
7 LASERS
0 - 9 BLACKOUT
10 - 49 RED LASER
50 - 89 GREEN LASER
90 - 129 RED & GREEN LASERS
Stinger
Master-Slave Set Up
With this feature you can connect the xtures to one another
using the IEC input and output sockets. The quantity that can be
connected is 10 xtures maximum. After 10 xtures you will need
to use a new power outlet. They must be the same xtures. DO
NOT mix xtures.
Stinger Power Cord Daisy Chain
Master-Slave Set Up: This function will allow you to link up to 16
units together and operate without a controller. In a Master-Slave
set-up one unit will act as the controlling unit and the others will react
to the controlling units programs. Any unit can act as a Master or as a
Slave.
1. Using standard XLR microphone cables, daisy chain your units
together via the XLR connector on the rear of the units. Remem-
ber the Male XLR connector is the input and the Female XLR
connector is the output. The rst unit in the chain (master) will use
the female XLR connector only - The last unit in the chain will use
the male XLR connector only. For longer cable runs we suggest a
terminator at the last fixture.
2. Set the Master to your desired operating mode.
3. Set the Slave unit(s) to address “001”.
4. The slave unit(s) will now follow the Master unit.
