ADJ XS 600 - 25 Channel DMX Mode Details

ADJ Products, LLC - www.adj.com - XS 600 User Manual Page 19ADJ Products, LLC - www.adj.com - XS 600 User Manual Page 18
XS 600 25 Channel Mode
Channel Value Function
18 COLOR MACROS & EFFECTS
11 - 20 RED
21 - 30 GREEN
31 - 40 RED & GREEN
41 - 50 BLUE
51 - 60 RED & BLUE
61 - 70 GREEN & BLUE
71 - 80 RED & GREEN & BLUE
81 - 123 SINGLE COLOR CHANGE
SLOW - FAST
124 - 166 COLOR MIX SLOW - FAST
167 - 209 COLOR FADE SLOW - FAST
210 - 249 COLOR CHANGE SLOW - FAST
250 - 255 SOUND ACTIVE COLOR EFFECT
19 STROBING
0 - 7 BLACKOUT
8 - 139 STROBING SLOW - FAST
140 - 189 SLOW OPEN - FAST CLOSE
190 - 231 FAST OPEN - SLOW CLOSE
240 - 255 RANDOM STROBE
20 0 - 255 MASTER DIMMER 0% - 100%
21 PROGRAMS
0 - 15 NOTHING
16 - 40 PROGRAM 1
41 - 65 PROGRAM 2
66 - 90 PROGRAM 3
91 - 115 PROGRAM 4
116 - 140 PROGRAM 5
141 - 165 PROGRAM 6
166 - 190 PROGRAM 7
191 - 215 PROGRAM 8
216 - 240 RANDOM PROGRAM PLAYING 5
TIMES EACH
241 - 255 RANDOM PROGRAM 2 MINS. EACH
XS 600 25 Channel Mode
Channel Value Function
22 0 - 255 PROGRAM SPEED SLOW - FAST
23 0 - 255 PAN/TILT SPEED FAST - SLOW
24 SPECIAL FUNCTIONS
0 - 69 NO FUNCTION
70 - 79 BLACKOUT WITH PAN/TILT
MOVEMENT
80 - 89 NO FUNCTION
90 - 99 BLACKOUT WITH RGBW VALUE
CHANGES
100 - 199 NO FUNCTION
200 - 209 RESET ALL
210 - 255 NO FUNCTION
25 DIMMER MODE
0 - 20 STANDARD
21 - 40 STAGE
41 - 60 TV
61 - 80 ARCHITECTURAL
81 - 100 THEATRE
101 - 255 DEFAULT DIMMER SETTING
