ADJ XS 600 - 31 Channel DMX Mode Details

ADJ Products, LLC - www.adj.com - XS 600 User Manual Page 20 ADJ Products, LLC - www.adj.com - XS 600 User Manual Page 21
XS 600 31 Channel Mode
Channel Value Function
20 0 - 255 HEAD 2 WHITE LED 0% - 100%
21 HEAD 1 COLOR MACROS & EFFECTS
0 - 10 NO FUNCTION
11 - 20 RED
21 - 30 GREEN
31 - 40 RED & GREEN
41 - 50 BLUE
51 - 60 RED & BLUE
61 - 70 GREEN & BLUE
71 - 80 RED & GREEN & BLUE
81 - 123 SINGLE COLOR CHANGE
SLOW - FAST
124 - 166 COLOR MIX SLOW - FAST
167 - 209 COLOR FADE SLOW - FAST
210 - 249 COLOR CHANGE SLOW - FAST
250 - 255 SOUND ACTIVE COLOR EFFECT
22 HEAD 2 COLOR MACROS & EFFECTS
0 - 10 NO FUNCTION
11 - 20 RED
21 - 30 GREEN
31 - 40 RED & GREEN
41 - 50 BLUE
51 - 60 RED & BLUE
61 - 70 GREEN & BLUE
71 - 80 RED & GREEN & BLUE
81 - 123 SINGLE COLOR CHANGE
SLOW - FAST
124 - 166 COLOR MIX SLOW - FAST
167 - 209 COLOR FADE SLOW - FAST
210 - 249 COLOR CHANGE SLOW - FAST
250 - 255 SOUND ACTIVE COLOR EFFECT
23 STROBING HEAD 1
0 - 7 BLACKOUT
8 - 139 STROBING SLOW - FAST
XS 600 31 Channel Mode
Channel Value Function
1 0 - 255 PAN
2 0 - 255 PAN FINE
3 0 - 255 TILT HEAD 1
4 0 - 255 TILT FINE HEAD 1
5 0 - 255 TILT HEAD 2
6 0 - 255 TILT FINE HEAD 2
7 PAN CONTINUOUS ROTATION
0 - 55 NO FUNCTION
56 - 127 CLOCKWISE ROTATION
128 - 199 COUNTER-CLOCKWISE ROTATION
200 - 255 NO FUNCTION
8 PAN CONTINUOUS ROTATION SPEED
0 - 255 SLOW - FAST
9 TILT 1 CONTINUOUS ROTATION
0 - 55 NO FUNCTION
56 - 127 CLOCKWISE ROTATION
128 - 199 COUNTER-CLOCKWISE ROTATION
200 - 255 NO FUNCTION
10 TILT CONTINUOUS ROTATION SPEED
0 - 255 SLOW - FAST
11 TILT 2 CONTINUOUS ROTATION
0 - 55 NO FUNCTION
56 - 127 CLOCKWISE ROTATION
128 - 199 COUNTER-CLOCKWISE ROTATION
200 - 255 NO FUNCTION
12 TILT CONTINUOUS ROTATION SPEED
0 - 255 SLOW - FAST
13 0 - 255 HEAD 1 RED LED 0% - 100%
14 0 - 255 HEAD 1 GREEN LED 0% - 100%
15 0 - 255 HEAD 1 BLUE LED 0% - 100%
16 0 - 255 HEAD 1 WHITE LED 0% - 100%
17 0 - 255 HEAD 2 RED LED 0% - 100%
18 0 - 255 HEAD 2 GREEN LED 0% - 100%
19 0 - 255 HEAD 2 BLUE LED 0% - 100%
