ADOBE FRAMEMAKER 10
MIF Reference
183
Usage
Values of the ShapeRect statement specify the coordinates and size of the bounding rectangle before it is rotated.
The equation is rotated by the value specified in an
Angle statement. The MathFullForm string defines the mathe-
matical properties of the equation. For a complete description, see “MathFullForm statement,” next.
Whenever you save a document as a MIF file using the Save As command, FrameMaker writes all the
Math substate-
ments, except
ObColor, to the file. It writes an ObColor statement only when the equation is in a color other than
black. The
ObColor statement specifies the color for the entire equation object. To specify color for an individual
element within an equation, use the formatting code
(*q string q*) (see “MathFullForm statement syntax” on
page 184).
If you are writing an output filter for converting FrameMaker equations to a format used by another application, you
might be able to ignore some of the
Math substatements. You don’t need MIF statements for FrameMaker’s math
features that are unsupported by another application.
If you are writing an input filter for converting equations created with another application to FrameMaker equations,
you must provide a
ShapeRect or MathOrigin substatement to specify the equation’s location on the page. The
other
Math substatements are not required. If you don’t provide them, the MIF interpreter uses preset values. If you
don’t define the equation in a
MathFullForm statement, an equation prompt appears in the FrameMaker document.
MathFullForm statement
The MathFullForm statement consists of a string containing a series of expressions that define the mathematical
structure of an equation. Each expression defines a component of the equation and can be nested within other
expressions.
A sample MathFullForm statement
This example shows an equation and the MathFullForm statement that defines it. The diagram shows the hierarchy
of the
MathFullForm statement. Symbols that appear in the equation are shown in parentheses following the
MathFullForm expression.
<MathFullForm `equal[char[y],times[char[a],power[id[plus[char[x],char[b]]],num[2,"2"]]]]'
> # end of MathFullForm
<MathSize keyword >
Equation size (defined on page 178)
keyword can be one of:
MathLarge
MathMedium
MathSmall
>
End of Math statement
yaxb+()
2
=
