Patent No. US 8,856,780 CA 2759622 FLRSBA Product Guide
ALARM ERROR CODES - 1 OF 1
ALARM ERROR CODES: NOTES PARKING LIGHT FLASHES ANTENNA LED FLASHES DIAGNOSTIC
I WARNING: The following applies only when the parking lights are
connected and supported by the system.
5 + 1 1 Shock sensor triggered
5 + 2 2 Door open
5 + 3 3 Trunk open
II If the alarm has been triggered, the parking lights will fl ash
fi ve [5x] times followed by the alarm activation event.
5 + 4 4 Hood open
5 + 5 5 Zone 2 input triggered
5 + 6 6 Foot brake ON
III The alarm event code is also displayed in a repeating pattern
on the antenna’s LED when the alarm is triggered, until unlock
is received.
5 + 7 7 Ignition ON
5 + 8 8 Motion detected
5 + 9 9 Tilt detected
5 + 10 10 Warn away input triggered
www.idatalink.comAutomotive Data Solutions Inc. © 2022 FLRSBA
PAGE 9 OF 45
• 20220110
