SPECIFICATIONS
Model V3 V5 V7 V10 V14
Rated Power (Hp) 2.4 2.5 3.2 2.5 x 2 3.2 x 2
Operating Current (A) 13 15 17 15 x 2 17 x 2
Fuse Rating (A) 25 25 25 25 25
Max Vacuum ("Hg) 7.5 7.5 7.5 7.5 7.5
Separation Tank (gal) 9.5 18.1 18.1 18.1 x 2 18.1 x 2
Flush Water Tube (Outer
Diameter)
⁄" ⁄" ⁄" ⁄" ⁄"
Intake Hose (Inner
Diameter)
1.5" 1.5" 1.5" 1.5" 1.5"
Drain Hose (Inner
Diameter)
1.5" 1.5" 1.5" 1.5" 1.5"
Exhaust Outlet (Inner
Diameter)
2" 2" 2" 2" 2"
Max Flow Rate
(CFM@7.5‘’Hg)
34 44 56 44 × 2 56 × 2
Noise (dB) 70 72 75 79 79
Net Weight (LBS) 191 216 238 227 × 2 249 × 2
Product Dimensions
(Inch)
15 × 17 × 48.8 18 × 19.3 × 48.7 18 × 19.3 × 48.7
(18 × 19.3 × 48.7)
× 2
(18 × 19.3 × 48.7)
× 2
Packaging Dimensions
(Inch)
21.5 x 22.7 x 52.3 26.6 x 23.4 x 55.7 26.6 x 23.4 x 55.7
(26.6 x 23.4 x 55.7)
× 2
(26.6 x 23.4 x 55.7)
× 2
No. Users 3--5 5 - 7 7 - 10 10 - 14 14 - 20
MAINTENANCE
WARNING
● Turn o the vacuum unit and disconnect main power before any maintenance to avoid injury or
equipment damage.
● The service panel is restricted to authorized technicians only. Do not attempt to access internal
components.
● Only perform the routine maintenance procedures described in this guide. For any other issues,
contact your ADS dealer to arrange service by a qualied technician. Attempting repairs without
proper training risks injury or damage.
CAUTION
Do not use cleaners containing oxidizing agents or with a pH less than 6 or greater than 8 on vacuum
lines. This includes bleaches, chlorine, iodine, peroxides, and other acidic or alkaline solutions. These
chemicals can cause dissolved mercury to recirculate through the system, leading to corrosion damage.
Use only non-foaming vacuum line cleaners and always follow the manufacturer's instructions. Contact
your authorized ADS dealer for recommendations on compatible vacuum line cleaning products. Proper
cleaning is essential to maintain your equipment and prevent premature wear, leaks, or other issues.
