ITC8113 / TabX® 41
© ads-tec Industrial IT GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen • Germany
10 Technical details
10.1 Technical details of the ITC8113
ITC8113
Housing
Glass-fibre reinforced monocoque frame
Display Resolution
13.3" TFT, Full HD, LED backlight
1920 x 1080 pixels
Touch
PCAP multifunction industrial touch screen (10-finger)
Processor
Intel® Intel® Celeron™ 1.6 GHz (2980U)
Intel® Core™ i5 1.9 GHz (4300U)
RAM
4 GB DDR3 RAM (optional 8 GB DDR3 RAM)
Mass storage
Hard drive 2.5" SATA, SSD (min. 100 GB)
Network
1 x Ethernet (10/100/1000 Mbit/s) RJ 45
Interfaces
2 x USB 3.0 (each port has a load capacity of max. 1 A)
Optional: 1 x USB 3.0, recessed installation (max. 1.8 A)
Docking connector
Optional: Display-Port
Power adapter
External power adapter (input 100-240 VAC; output 20 VDC)
BIOS battery
Lithium battery CR2032 230mAh
Article no. ADS-TEC: DZ-SONS-04075-1
Operating system
Windows
©
Embedded Standard 7 (64 bit)
Windows
©
Embedded 8.1 Industry Pro (64 bit)
Windows
©
10 IoT
Protection class
IP 53 / front IP 65 (tested by ADS-TEC, not evaluated by UL)
Operating temperature
0 to +40°C
Dimensions (W x H x D)
356 x 262 x 42 mm (73 mm with tip-up feet in the folded out position)
Weight
Approx. 1.8 kg without batteries
Vibration
DIN EN 60068-2-6
Shock resistance
DIN EN 60068-2-27
Humidity
10 to 85% non-condensing
k/Ser vic e u nd S upp ort/ Ser vice & S up port @ 2 \mod_1254312498746_6.doc @ 6472 @
