ITC8113 / TabX® 58
© ads-tec Industrial IT GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen • Germany
2) Screw down the strap eyelets at the marked positions as shown in the
figure.
Recommendation for use:
Tighten the screws to max. 120 Ncm. The strap eyelets should still
move without loosening the screw.
Mounted state for right-handed users
