• Connect the power cable into the back of the camera.
• Insert the grommet between the camera and the power input cover.
Caution: Ensure that the grommet is positioned properly to
prevent water from entering the camera power input.
• At the location of the power source, connect the power cable to the power
adapter:
• Screw the red wire onto the positive (+) terminal of the power adapter, on
the left side.
• Screw the black wire onto the negative (–) terminal of the power adapter,
on the right side.
• Adjust the camera to the desired position and secure it firmly.
• Verify that the camera is active on the wireless network and is recognized
by the platform.
Caution: To avoid damaging the camera, be sure to observe proper
polarity. Although the + and – terminals are marked on the power
adapter, they are white on white and may be difficult to see.
