Adtech CNC Technology Co., Ltd. 11. Program saving & editing
- 54 -
029
Inp Speed(mm/min)
030 InpStartSpeed(mm/min)
031 InpAcceleration(mm/sec)
039
XBacklashExpiate(pulse)
Range : 1~9999, 1~9999, 1~8000, 1~9999
Unit : mm/min,mm/min,mm/sec,mm/min
Authority : Operation admin or higher
Default : 3000,200,1000,3000
Effective time : Instant
Note : The feeding instructions such as G01, G02 and G03 move at the speed of
F instruction. If the F instruction isn’t specified in the program, the above
instructions move at the speed set by this parameter. If the F instruction
is specified, this parameter will be invalid.
The maximum feeding speed restricts the F instruction during
processing, i.e. no matter what F is set to, the actual speed can’t exceed
this parameter value. Setting this parameter will prevent the damage
caused by accidental speed programming error when transferring
processing files.
032
XBacklashExpiate(pulse)
033 YBacklashExpiate(pulse)
034 ZBacklashExpiate(pulse)
035 4BacklashExpiate(pulse)
Range : 1~20000
Unit : Pulse
Authority : Operation admin or higher
Default : 0
Effective time : Instant
Note : Compensate the clearance between control axis
Compensate with the pulse in minimum unit. The specific number should
be converted according to gear ratio.
036 ZeroReturn Mode
Range : 0~1
Unit : None
Authority : Operation admin or higher
Default : 0 (program)
Effective time : Instant
Note : 0 - Program home
1 - Mechanical home
Program home is that the coordinates go to home, i.e. in place.
Mechanical home requires external detection switch to locate the home
position; while home operation, move to specified home direction at
home speed, and move back slowly after signal is detected. At this
moment, move forward slowly when the signal is disconnected, and the
home operation completes when the signal is valid again. When the servo
Z phase enable switch in IO configuration parameters is enabled,
mechanical home will enable Z phase positioning as home position
automatically after signal reaches.
037 IO FilterWave(1~8)
Range : 0~8
Unit : None
Authority : Super Admin
Default : 0
Effective time : After restarted
Note : Set the filter constant;
If the environment has too much interference, e.g. rain and thunder,
please enter a filter value. Higher value indicates longer test time and
high reliability; 0 indicates no filter;
