Adtech CNC Technology Co., Ltd. 11. Program saving & editing
- 60 -
Default : 1 (L series) /0 (M series)
Effective time : Instant
Note : On lathe controller (L series), it is used to set whether the display and
programming of X axis are in radius or diameter;
087 default process plane
Range : G17,18,19
Unit :
Authority : Operation admin or higher
Default : G18 (L series)/G17 (M series)
Effective time : Instant
Note : Set the default processing plane to XY or XZ; modify the default plane,
so that it isn’t need to specify the modal plane value while programming,
and write plane related instructions directly in stead;
088 T code form
Range : 0~2
Unit :
Authority : Operation admin or higher
Default : 2 (L series)
Effective time : Instant
Note : Used to set the T value in tool change instruction on lathe controller (L
series); the latter digits indicate the compensation number. In some
conventional programming, people usually use two digits to specify the
compensation number used by corresponding tool number;
For example: T0801 M06 indicates changing the #8 tool and
compensating with #1 length.
089 IP address
090 subnet mask
091 default gateway
Range :
Unit :
Authority : Operation admin or higher
Default : 192.168.0.123
255.255.255.0
192.168.0.1
Effective time : Restart
Note : Used to configure Ethernet parameters, which shall comply with the
actual network settings, or else it can’t be accessed normally.
After configured successfully, the user can perform the ping command
test on the PC of same network segment (same subnet mask) in the
intranet. The connection has error if the return overtimes. Please check
the physical connection.
The network environment requires independent NC network. Do not
connect to office network or Internet, because the broadcast in the
network and regular query of windows will block the network
communication of NC.
