3. Install New Parts and Reassemble the Jet
3.1 Overview
In general, parts are reinstalled in the reverse order that they were removed.
Gather the screws set aside as shown in Section 2.7.
Install the Main Air Valve and Hammer Cylinder
Attach the air valve
Attach the silencer
Install the hammer air cylinder.
Assemble the Spacer
Assemble the lever and lever spring
Attach the spacer
Align the lever
Install the pivot (shoulder) bolt
Reassemble the Heater Block
Install the heater seal, washer, and hammer spring
Install the bushing
Align and attach heater block
Attach the Valve Mount
(Optional) Replace Melter Cable
Reassemble the Jet
Insert nozzle plate screws
Position and attach melter assembly and top cover
Tuck cables
Attach air valve connector
Attach the mounting plate
Attach the dovetail plate
Use Loctite
®
242 threadlocker as indicated. To avoid damage to the jet,
do not substitute with other products.
3A6328A Advanjet HM-2600 Hotmelt Jet Maintenance and Repair Page 17 of 28
