ADAM-6300 User Manual
70
Address (4X):
0x0065
12
DI Stop/Start Counter
R/W
0x0066
13
0x0067
14
0x0068
15
0x0069
16
0x0070
17
0x0073
12
DI clear counter
R/W
0x0074
13
0x0075
14
0x0076
15
0x0077
16
0x0078
17
0x0081
12
DI enable/disable filter
R/W
0x0082
13
0x0083
14
0x0084
15
0x0085
16
0x0086
17
0x0089
12
DO start/stop pulse
R/W
0x0090
13
0x0091
14
0x0092
15
0x0093
16
0x0094
17
Address (4x)
Ch
annel
Description
Attribute
4x0033
12
DI Counter V
alue
Read
4x0034
4x0035
13
4x0036
4x0037
14
4x0038
4x0039
15
4x0040
4x0041
16
4x0042
4x0043
17
4x0044
75
77
Table of Contents
Default Chapter
5
Table of Contents
5
Chapter 1 Product Overview
7
ADAM-6300 Introduction
8
Features
8
Hardware Introduction
8
Front Name Plate
8
Power Connection
9
Ethernet Connector and Grounding Screw
9
LED Definition
9
Dimensions
10
Package Information
10
Chapter 2 Hardware Installation
11
Mounting: DIN Rail
12
Power Supply Wiring
12
I/O Module Wiring
13
Chapter 3 Introduction to Digital I/O
15
Specifications
16
General
16
Protection
16
Environment
16
OPC UA Specification
16
Digital Input/Output Modules (ADAM-6350)
17
Specifications
17
Application Wiring
17
Analog Input Modules (ADAM-6317)
19
Specifications
19
Application Wiring
19
SSR Relay Output Module Modules (ADAM-6360D)
21
Specifications
21
Application Wiring
22
Relay Output Module Modules (ADAM-6366)
24
Specifications
24
Application Wiring
25
Chapter 4 System Configuration
27
System Requirements
28
Installing Adam/Apax .NET Utility
28
Adam/Apax .NET Utility Overview
29
Menu Bar
30
Toolbar
31
Module Tree Display Area
32
Status Display Area
32
Configuration of ADAM-6300 Modules
33
The Information Tab
34
The Network Tab
34
The Administration Tab
35
The Firmware Tab
35
Getting Started: the Connection of OPC UA Server and Client
36
NET Utility)
36
Network and I/O Type Setting
36
Connection of OPC UA Server and OPC UA Client
39
I/O Configuration
44
Analog Input
44
Digital Input
52
Digital Output
59
SSR Relay Output
67
Appendix A Modbus Table
69
ADAM-6317: 8AI/11DI/10DO Iot Modbus/Opc UA Ethernet Remote I/O
70
ADAM-6350: 18DI/18DO Iot Modbus/Opc UA Ethernet Remote I/O
75
ADAM-6360D: 8Relay(SSR)/14DI/6DO Iot Modbus/Opc UA Ethernet Remote I/O
79
ADAM-6366: 6 Relay /18 DI/ 6 DO Iot Modbus/Opc UA Ethernet Remote I/O
83
4
