ADAM-6300 User Manual
Appendix A
Modbus Table
A.3
ADAM-6360D: 8Relay(SSR)/14
DI/6DO IoT
Modbus/OPC UA
Ethernet Remote I/O
Address (0X):
Address (0x)
Channel
Description
Attribute
0x0001
0
DI V
alue
Read
0x0002
1
0x0003
2
0x0004
3
0x0005
4
0x0006
5
0x0007
6
0x0008
7
0x0009
8
0x0010
9
0x001
1
1
0
0x0012
1
1
0x0013
12
0x0014
13
0x0033
0
SSR V
alue
R/W
0x0034
1
0x0035
2
0x0036
3
0x0037
4
0x0038
5
0x0039
6
0x0040
7
0x0041
0
DO V
alue
R/W
0x0042
1
0x0043
2
0x0044
3
0x0045
4
0x0046
5
0x0065
8
DI Stop/Start Counter
R/W
0x0066
9
0x0067
10
0x0068
1
1
0x0069
12
0x0070
13
78
80
