ADAM-6300 User Manual
Appendix A
Modbus Table
A.2
ADAM-6350: 18DI/18DO IoT Modb
us/OPC UA
Ethernet Remote I/O
Address (0X):
Address (0x)
Cha
nnel
Description
Attribute
0x0001
0
DI V
alue
Read
0x0002
1
0x0003
2
0x0004
3
0x0005
4
0x0006
5
0x0007
6
0x0008
7
0x0009
8
0x0010
9
0x001
1
10
0x0012
1
1
0x0013
12
0x0014
13
0x0015
14
0x0016
15
0x0017
16
0x0018
17
0x0033
0
DO V
alue
R/W
0x0034
1
0x0035
2
0x0036
3
0x0037
4
0x0038
5
0x0039
6
0x0040
7
0x0041
8
0x0042
9
0x0043
10
0x0044
1
1
0x0045
12
0x0046
13
0x0047
14
0x0048
15
0x0049
16
0x0050
17
74
76
Table of Contents
Default Chapter
5
Table of Contents
5
Chapter 1 Product Overview
7
ADAM-6300 Introduction
8
Features
8
Hardware Introduction
8
Front Name Plate
8
Power Connection
9
Ethernet Connector and Grounding Screw
9
LED Definition
9
Dimensions
10
Package Information
10
Chapter 2 Hardware Installation
11
Mounting: DIN Rail
12
Power Supply Wiring
12
I/O Module Wiring
13
Chapter 3 Introduction to Digital I/O
15
Specifications
16
General
16
Protection
16
Environment
16
OPC UA Specification
16
Digital Input/Output Modules (ADAM-6350)
17
Specifications
17
Application Wiring
17
Analog Input Modules (ADAM-6317)
19
Specifications
19
Application Wiring
19
SSR Relay Output Module Modules (ADAM-6360D)
21
Specifications
21
Application Wiring
22
Relay Output Module Modules (ADAM-6366)
24
Specifications
24
Application Wiring
25
Chapter 4 System Configuration
27
System Requirements
28
Installing Adam/Apax .NET Utility
28
Adam/Apax .NET Utility Overview
29
Menu Bar
30
Toolbar
31
Module Tree Display Area
32
Status Display Area
32
Configuration of ADAM-6300 Modules
33
The Information Tab
34
The Network Tab
34
The Administration Tab
35
The Firmware Tab
35
Getting Started: the Connection of OPC UA Server and Client
36
NET Utility)
36
Network and I/O Type Setting
36
Connection of OPC UA Server and OPC UA Client
39
I/O Configuration
44
Analog Input
44
Digital Input
52
Digital Output
59
SSR Relay Output
67
Appendix A Modbus Table
69
ADAM-6317: 8AI/11DI/10DO Iot Modbus/Opc UA Ethernet Remote I/O
70
ADAM-6350: 18DI/18DO Iot Modbus/Opc UA Ethernet Remote I/O
75
ADAM-6360D: 8Relay(SSR)/14DI/6DO Iot Modbus/Opc UA Ethernet Remote I/O
79
ADAM-6366: 6 Relay /18 DI/ 6 DO Iot Modbus/Opc UA Ethernet Remote I/O
83
