3 Chapter 1
Touchscreen (Optional)
• Type: 5 wire, analog resistive
• Resolution: 1280 x 1024
• Light Transmission: >80% (Gouge Hardness is greater tahn 4H per
ASTM D3363-92 for HCC01, HCG10 and HCG12
• Operating Pressure: 30 ~ 45 gram for stylus pen
contact bounce < 15 ms
• Controller: USB & RS-232 interface
• Power Consumption: 5.5V or less, 70mA (maximum)
• OS Support: Windows 2000/XP/CE/Vista, Linux, MS-DOS
• Life Span: Touch panel is hit 36 millions times with a silicone rubber
of R8 finger, hitting rate is by 250g at 2 times per second.
1.3 LCD Specifications
• Display Type: SXGA TFT LCD
• Display Size: 19"
• Max. Colors: 16.2M colors 8-bits (6-bits+HiFRC)
• Max. Resolution: 1280 x 1024
• Dot Pitch: 0.294 (per one triad) x 0.294
• View Angle: 160° (V), 160° (H)
• Luminance: 300 cd/m2
• Storage Temperature: -20 ~ 60 ° C
• Operating Temperature: 0 ~ 50 ° C
• Contrast Ratio: 1300:1 (typ)
• Lamp Life Time (MTBF): 50,000 hrs.
1.4 Power Consumption
• Max. Output Power: 57 W
• AC Input Voltage: 100-240 V
AC
• Output Voltage: + 12 V @ 4.7A
• Safety Standards: BSMI, CE, FCC, CCC, UL
