FPM-5191G User Manual 8
Chapter 2 Mounting
2.1 Mounting the Monitor
The FPM-5191G Series can be mounted in many different ways. The
versatility of the FPM-5191G mounts enable it to be mounted on your
desk or anywhere else.
2.1.1 Wallmounting (Optional)
FPM-5191G can be mounted directly on a wall with panel mounting
brackets. Customers must order the stand kit for FPM-5191G (Part Num-
ber: FPM-5191G-SMKE). Please refer to figure 2-1 and follow the fol-
lowing steps to mount FPM-5191G on a wall:
1. Screw the hook and desk-stand brackets on the wall.
2. Attach 4 screws around the bracket
3. Put the Industrial monitor into the screws around the bracket
Figure 2.1: Wallmounting
