11 Chapter 2
2.2 Desktop, Swing-ARM for FPM-5191G
The FPM-5191G Series can be mounted in other ways, such as desktop
and swing-arm.
2.2.1 Desktop Stand (Optional)
FPM-5191G can be mounted as stand in the desk directly by a additional
mounting brackets. Customers must order the stand kit for FPM-5191G
(Part Number: FPM-5191G-SMKE). Please refer to figure 2-4 and follow
these steps:
Figure 2.4: Desktop Stand
