2.2 BootingfromnetworkviaPXE
TobootanOSvianetwork,pleasemakesurethefollowingBIOSoptionsIntheAdvanced:NetworkStack
ConfigurationMenuisconfiguredproperly:

BIOSitem
CSMParameters‐>Network
BIOSitem
NetworkStack
PXEsetting
Donotlaunch
Disabled DisabledPXE
Enabled DisabledPXE
UEFI
Disabled DisabledPXE
Enabled EnabledUEFIIPV4PXE
Legacy
Disabled EnabledlegacyIPV4PXE
Enabled EnabledlegacyIPV4PXE
Table1:PXEBIOSOptions

BelowarethestepstoenablePXEboot.
1.Whenusersets“BIOS/Advanced‐>CSMParameters‐>Network”asLegacytoenablePXEROMfunction,
setitas“Legacy”(IPV4PXE)function.


