2.3 LEDBehaviour
2.3.1 FORTHEDESCRIPTIONOFLANPORTLEDS

2.3.2 SFPLEDINDICATORFUNCTIONINFRONT:

Figure:SFPconnectordrawing
SFPLED LEFT RIGHT
SFP1 SPEED:1GGreen
LINK/ACKLINK:GreenACK:
GreenBlinking
SFP2 SPEED:1GGreen
LINK/ACKLINK:GreenACK:
GreenBlinking
Table2:SFPconnectorLEDindication
2.3.3 RJ45LEDINDICATORFUNCTIONINFRONT:
RJ45LED LEFT RIGHT
1
SPEED:10MLEDOFF
100MAmber,1G
Green
LINK/ACKLINK:GreenACK:
GreenBlinking
2
SPEED:10MLEDOFF
100MAmber,1G
Green
LINK/ACKLINK:GreenACK:
GreenBlinking
Table3:RJ45connectorLEDindication(MarvellPHY)
