Figure19:PlatformSetup:ConsoleRedirectionMenu


ThesettingsforCOM0consolecanbeaccessedinthismenu.
Thissubmenuallowsyoutochangethesettingsusedfortheserialconsole.Forexample,userscandefine
theterminaltype,bitspersecond,databits,parity,stopbitsandothers.
Setupitem Access/Options Description
ConsoleRedirection
Disabled/
Enabled
Disabled/EnabledConsoleRedirection
SerialConsolePort COM0 SerialConsolePort
SerialConsole
Speed
9600/19200/
38400/57600/
115200
Definesthebaudrate.
DataBits 7/8 Definesnumberofdatabitsinacharacter.
StopBits 1/2 Definesnumberofstopbitsinacharacter.
Parity
None/Even/Odd
/Mark/Space
Definestheparityschemeused.
FlowControl None/Xon/Xoff Definestheflowcontrolscheme.
TerminalType
ANSI/VT100/
VT100+/
Selectthetargetterminalemulationtype:‐ANSItousethe
ExtendedASCIICharacterSet.
