Advantech LNC-5800D User Manual

Product introduction
14 Advantech LNC Technology Co., Ltd.
Advantech-LNC
 STP(Shielded Twisted Pair cable) TIA/EIA-568B CAT 5e cable must be used to prevent noise.
 Don’t lay signal wires in the same duct or bundle with power lines.
1.4.2.3 5800D3 EhterCAT
◎ Description: Connected to EtherCAT Devices
◎ Wiring example as below
 STP(Shielded Twisted Pair cable) TIA/EIA-568B CAT 5e cable must be used to prevent noise.
 Don’t lay signal wires in the same duct or bundle with power lines
(1)
5800D3 controller (Master station)
Slave station
Slave station
Slave station
……
Slave station
