3 I/O Mapping
Internal I/O
I point
O point
Title
Serial No.
Title
Serial No.
L_IN1
20000
Servo_Reset
20003
L_IN2
20001
±IN
20002
MPG Axis_X
20006
MPG Axis_Y
20007
Servo_ON_SP1(AXIS1)
20020
MPG Axis_Z
20008
Servo_ON_SP2(AXIS2)
20021
MPG Axis_4
20009
MPG Axis_5
20010
MPG Axis_6
20011
MPG Rate_x10
20012
MPG Rate_x100
20013
Servo_Alarm_SP1(AXIS 1)
20014
Servo_Alarm_SP2(AXIS 2)
20015
Initial key (the red key on the
back of mainframe)
20033
Digital PCC3320/PCC3370=1
20063
Lathe Machine OP panel (OP-2133)
I point
O point
Name of key
Serial No.
Name of indicator
Serial
No.
CYCLE_START
20100
CYCLE_START
20104
FEED_HOLD
20101
FEED_HOLD
20105
↓X
20091
↓X
20095
↑X
20067
↑X
20071
Y+
20092
Y+
20096
Y－
20090
Y－
20094
→Z
20080
→Z
20084
←Z
20078
←Z
20082
C+
20068
C+
20072
C－
20066
C－
20070
MPG_DRN
(handwheel simulation)
20082
MPG_DRN
(handwheel simulation)
20086
SBK(single block execution)
20070
SBK(single block execution)
20074
BDT(optional skip)
20083
BDT(optional skip)
20087
