Advantech LNC-5800D User Manual

I/O Mapping
34 Advantech LNC Technology Co., Ltd.
Advantech-LNC
OP_STOP(optional stop)
20071
OP_STOP(optional stop)
20075
Spindle CW(clockwise)
20069
Spindle CW(clockwise)
20073
Spindle STOP
20081
Spindle STOP
20085
Spindle CCW
(counterclockwise)
20093
Spindle CCW
(counterclockwise)
20097
COOL
(cutting cooling water)
20109
COOL
(cutting cooling water)
20136
W.L.(Working light)
20108
W.L.(Working light)
20135
CK(clamp)
20085
CK(clamp)
20089
AIR_BLOW(air blowing)
20098
AIR_BLOW(air blowing)
20102
TUR_CW(turret clockwise)
20072
TUR_CW(turret clockwise)
20076
TUR_CCW
(turret counterclockwise)
20073
TUR_CCW
(turret counterclockwise)
20077
CTCH(catcher)
20074
CTCH(catcher)
20078
AUTO (automatic)
20084
AUTO (automatic)
20088
F1
20075
F1
20079
F2
20087
F2
20091
F3
20099
F3
20103
TB(tail stock)
20086
TB(tail stock)
20090
MEM(automatic mode)
20089
MEM(automatic mode)
20093
MDI(manual mode)
20088
MDI(manual mode)
20092
INC JOG
(increase jog mode)
20065
INC JOG
(increase jog mode)
20069
JOG(jog mode)
20064
JOG(jog mode)
20068
MPG(handwheel mode)
20077
MPG(handwheel mode)
20081
ZRN(zero point mode)
20076
ZRN(zero point mode)
20080
Feed rate F%+(feed +)
20107
Feed rate 100%
20106
Feed rate F%-(feed －)
20105
Spindle speed UP
(rotational speed＋)
20104
Spindle speed 100%
20103
Spindle speed DOWN
(rotational speed -)
20102
Rapid LOW
20094
Rapid LOW
20098
Rapid 25%/MPGx1
20095
Rapid 25%/MPGx1
20099
Rapid 50%/MPGx10
20096
Rapid 50%/MPGx10
20100
Rapid 100%/MPGx100
20097
Rapid 100%/MPGx100
20101
RAPID
(rapid selection mode)
20079
RAPID
(rapid selection mode)
20083
IO_READY(IO is normal)
20067
Zero(zero complete)
20064
NC_READY(system is normal)
20066
