Advantech LNC-5800D User Manual

I/O Mapping
Advantech LNC Technology Co., Ltd. 37
Advantech-LNC
Lathe Machine OP panel (OP-3360A2)
I point
O point
Name of key
Serial No.
Name of indicator
Serial
No.
CYCLE_START
20121
CYCLE_START
20125
FEED_HOLD
20120
FEED_HOLD
20124
↓X
20105
↓X
20109
↑X
20089
↑X
20093
Y+
20088
Y+
20092
Y－
20104
Y－
20108
→Z
20098
→Z
20102
←Z
20096
←Z
20100
←B
20081
←B
20085
→B
20082
→B
20086
C+
20090
C+
20094
C－
20106
C－
20110
MPG_DRN
(handwheel simulation)
20071
MPG_DRN
(handwheel simulation)
20075
SBK(single block execution)
20070
SBK(single block execution)
20074
BDT(optional skip)
20086
BDT(optional skip)
20090
OP_STOP(optional stop)
20078
OP_STOP(optional stop)
20082
Spindle CW(clockwise)
20067
Spindle CW(clockwise)
20071
SpindleSTOP
20068
Spindle STOP
20072
SpindleCCW(counterclockwise)
20069
Spindle CCW(counterclockwise)
20073
Power Tool 2
20075
Power Tool 2
20079
Power Tool 3
20077
Power Tool 3
20081
FEEDER
20087
FEEDER
20091
COOL(cutting cooling water)
20095
COOL
20099
W.L.(Working light)
20094
W.L.
20098
CK(clamp)
20076
CK(clamp)
20080
AIR_BLOW(air blowing)
20102
AIR_BLOW(air blowing)
20106
DOOR
20103
DOOR
20107
TUR_CW(turret clockwise)
20084
TUR_CW(turret clockwise)
20088
TUR_CCW
(turret counterclockwise)
20085
TUR_CCW
(turret counterclockwise)
20089
CHIP CW
20110
CHIP CW
20114
CHIP CCW
20111
CHIP CCW
20115
CTCH(catcher)
20083
CTCH(catcher)
20087
AUTO(automatic)
20079
AUTO(automatic)
20083
F1
20118
F1
20122
F2
20112
F2
20116
