TO REMOVE COVER OF MAINS
TERMINAL
From the rear of the cooker, remove mains input
terminal cover to gain access to terminal block.
First remove retaining screw with pozidrive
screwdriver. See Fig. 4.
Prise cover loose using screwdriver in position
(1) then lever off with screwdriver in position (2)
at either side. See Fig. 5.
Lift cover and remove screw from cable clamp.
See Fig. 6.
51
Fig.4
Fig.5
Fig.6
