CAUTION!
Connections via contact plugs are
forbidden.
CAUTION!
Do not drill or solder the wire ends. It is
forbidden.
CAUTION!
Do not connect the cable without cable
end sleeve.
N
L1
N
L
220-240 V~220-240 V~ 400V2N~
L2
N
N
L1
L2
220 - 240 V~
Two-phase connection: 400 V2N~ One-phase connection: 220
- 240 V~
5x1,5 mm² 5x1,5 mm² or 4x2,5 mm² 5x1,5 mm² or 3x4 mm²
Green - yellow Green - yellow Green - yellow
N Blue and blue N Blue and blue N Blue and blue
L1 Black L1 Black L Black and brown
L2 Brown L2 Brown
4. PRODUCT DESCRIPTION
4.1 Product overview
3
2
1
4
5
6
7
7 6 5 48
8
ENGLISH 9
