Page 3
Introduction
Congratulations on your purchase of the AEM Water/Methanol Injection Kit. This document will
help guide you through the setup and installation process. Please take the time to review its
contents prior to installation. Pay especially close attention to any bolded text, as it indicates an
important note, or step in the process.
Before beginning installation of electronic components please disconnect the ground side of the
battery. This is for your safety.
Specifications
1 Gallon tank with integral level sensor
200 PSI injection pump
Progressive pump controller with “Boost Safe” feature
High amperage pump driver with over-current, over-voltage and under-voltage protection
Error protection output with over-current, over-voltage and over-temperature protection
Two system status LED indicators; shows pump duty cycle and system errors
Pump open and short detection and indication; works even if the pump is off
Test button that manually triggers pump
Two dial pump speed control
Bolt, Hex Head, 5/16-18 x 1.25”
Bolt, Hex Head, 8-32 x 1.5”
Screw, Pan Head #8 x 1.0"
Screw, Pan Head #6 x 0.5"
Butt Connector, 14-16 AWG (blue)
Butt Connector, 18-22 AWG (red)
Ring Terminal, 14-16 AWD (blue)
High Pressure ¼” Nylon Hose
1 Gallon Tank With Integral Fluid
Level Sensor
10”h x 8.5”w x 4.25”d
200 PSI Pump With Integral Fittings
Progressive Injection Module
