Digital Megohmmeter Model 1026
- 5 -
General Specifications:
Display:
3" x 1.7" (76 x 42mm)
Big LCD panel with 40 segments analog bar indication.
Over Range Indication:
“
- O L - ” will be shown on the LCD Panel when out of range measurement
is made.
Low Battery Indication:
The will be shown when the batteries needs to be changed.
Sampling Rate:
2.5 times/sec digital display; 10 times/sec bar graph
Power Source:
(8) 1.5V AA size batteries
Battery Life:
1000V range @ 1 M >10H
500V range @ 1 M >20H
250V range @ 1 M >30H
Operating Temperature and Humidity:
0° to 40°C (32° to 104°F), below 80% RH
Storage Temperature:
-10° to 60°C (14° to 140°F)
Dimension:
7.72" (L) × 4.41" (W) × 2.52" (H)
196mm (L) × 112mm (W) × 64mm (H)
Weight:
Approx. 700g (1.5 lbs) with batteries
