AEOTEC Engineering Specification
Page 9
(2) Different protection trigger
Protection trigger
Activation condition
Result
How to cancel/disable
Local Protection
Protection Set:
Local Protection State = 2
No operation possible. It is not
possible at all to control a device
directly via the user interface.
Protection Set:
Local Protection State = 0
RF Protection
Protection Set:
RF Protection State = 1
No RF control - all runtime
Commands are ignored by the
device.
Protection Set:
RF Protection State = 0
Alarm Report
Receive any alarm enabled by
Alarm Settings (Parameter 9)
(1)Switch will react based on
Alarm Response (Parameter 8),
and Indicator Light will keep
blinking based on Parameter 18.
(2)Local Protection State will NOT
automatically change to be 2.
However, it is not possible at all to
control a device directly via the
user interface until alarm is
disable.
(3)RF Protection State will NOT
automatically change to be 1.
However, Switch will report
Application Rejected Request
when receives any command
which can control the switch state
until alarm is disable.
Based on the setting to
disable alarm (Parameter
10).
Note:
Power off will also disable
the alarm response without
any limitation.
Over-current detected
The current of the load
connected is over 11A.
(1)Blinking red light.
(2)Turn off switch.
(3)Local Protection State will
automatically change to be 2. It is
not possible at all to control a
device directly via the user
interface until users set the Local
Protection State to be
0(unprotected).
(4)RF Protection State will
automatically change to be 1.
Switch will report Application
Rejected Request when receives
any command which can control
the switch state until users set the
RF Protection State to be
0(unprotected).
Protection Set:
Local Protection State = 0
RF Protection State = 0
Over-load detected
The power of the load
connected is over the
threshold value.(Parameter 4)
(1)Blinking red light.
(2)Turn off switch.
(3)Local Protection State will
automatically change to be 2. It is
not possible at all to control a
device directly via the user
interface until users set the Local
Protection State to be
0(unprotected).
(4)RF Protection State will
automatically change to be 1.
Switch will report Application
Rejected Request when receives
any command which can control
the switch state until users set the
RF Protection State to be
0(unprotected).
Protection Set:
Local Protection State = 0
RF Protection State = 0
