Switch will turn ON in 5 seconds, and then turn OFF in 5 seconds in a
cycle until user disables the alarm manually
Note:
When receives any alarm enabled by Alarm Settings, Indicator Light will keep
blinking based on Parameter 0x12 (18). It will prohibit user from manually or RF
control the switch state until the alarm is disable.
0x09(9)
Alarm Settings.
Determine if alarms are enabled in Switch, and what Switch will react to which
alarm. The format of the parameter is Bit field (Checkboxes). The parameter MUST
be treated as a bit field where each individual bit can be set or reset. A graphical
configuration tool SHOULD present this parameter as a series of checkboxes.
7 6 5 4 3 2 1 0
Value1 Reserved Home
Security
Access
Control
Water
Alarm
Heart
Alarm
CO2
Alarm
CO
Alarm
Smoke
Alarm
Value2
Reserved
Access
Control
trigger
state
Value1: Supported Notification Type and Notification Event
Value Notification Type Notification Event
1 Smoke Alarm State idle
Smoke detected (location provided)
Smoke detected
2 CO Alarm State idle
Carbon monoxide detected (location provided)
Carbon monoxide detected
4 CO2 Alarm State idle
Carbon dioxide detected (location provided)
Carbon dioxide detected
8 Heart Alarm State idle
Overheat detected (location provided)
Overheat detected
16 Water Alarm State idle
Water leak detected (location provided)
Water leak detected
32 Access Control State idle
Window/door is open
Window/door is closed
64 Home Security State idle
Intrusion (location provided)
Intrusion
Motion detection (location provided)
Motion detection
Value2: Access Control trigger state:
Value Description
0 Alarm will be triggered by open state, and be disable by closed state or
idle state
1 Alarm will be triggered by closed state, and be disable by open state or
idle state
Example:
If the parameter value equals to 8704(0x2200), Alarm Response will active when
receives Carbon monoxide detected or Window/door is open.
If the parameter value equals to 8705(0x2201), Alarm Response will active when
receives Carbon monoxide detected or Window/door is Closed.
WR
0
2
0x0A(10)
Setting to disable alarm.
Determines the method of disabling the alarm of the device.
Value Description
WR
0
2
